293
Label Width
Shows the necessary media width of the test print.
The necessary media width is 76.2 mm (3") for [Large].
Pitch
Set the print position in the vertical direction.
The setting range is from -45 to +45 dots.
When you decrease the setting value, the print position moves in the feed direction.
When you increase the setting value, the print position moves opposite the feed direction.
Offset
Set the tear-off position/cut position/dispense stop position.
The setting range is from -45 to +45 dots.
When you decrease the setting value, the stop position moves in the feed direction.
When you increase the setting value, the stop position moves opposite the feed direction.
Darkness Adjust
Fine tune the print darkness of the test print.
0 is the lightest and 99 is the darkest.
• The length of 1 dot is 0.083 mm (0.0033").
• You can change the unit to dots or inches in the [System] > [Regional] > [Unit] menu.
• The value of [Pitch], [Offset] and [Darkness Adjust] set in the [Factory] menu will be
reflected to the same item settings in the [Configure List] menu, [Configure QR] menu,
[Paper Sensor] menu and [BD address] menu.
[Configure List]
Print the printer setting information.
1. Check and set the items as listed on the [Configure List] menu.
2.
Tap to start the test print. Tap to pause the print.
To stop the test print, first pause the print and then tap .
The setting items are as follows:
Category
Select the category of the list to print.
The options are as follows:
◦ [All]
◦ [Information]
◦ [Printing]
◦ [Interface]
To Next Page
