SATO FX3-LX User Manual

[Wi-Fi Setting]
320
[Netmask]
Set and check the subnet mask address.
If you have selected [DHCP] in the [Mode] menu, the screen shows the subnet mask address you
received from the DHCP server.
If you have selected [Static] in the [Mode] menu, set the subnet mask address.
Each group of the address can be set among 0, 128, 192, 224, 240, 248, 252, 254 and 255.
The setting range is as follows:
128.000.000.000 to 255.255.255.254
[Gateway]
Set and check the default gateway address.
If you have selected [DHCP] in the [Mode] menu, the screen shows the gateway address you received
from the DHCP server.
If you have selected [Static] in the [Mode] menu, set the default gateway address.
The setting range is as follows:
000.000.000.000 to 255.255.255.255
• The gateway address set here is shared with the settings in [Interface] > [Network] >
[Settings] > [LAN] > [IPv4 (LAN)].
[DNS]
If you have selected [Static] in the [Mode] menu, set and check DNS server addresses.
The setting range is as follows:
000.000.000.000 to 255.255.255.255
•
You can register up to three IP addresses for the DNS server. Tap to add different
IP addresses.
• The DNS server addresses set here are shared with the settings in [Interface] >
[Network] > [Settings] > [LAN] > [IPv4 (LAN)].
[IPv6 (Wi-Fi)]
Configure IPv6 for Wi-Fi.
•
After doing the settings, tap or press the / (Standby/Home) button. A
message asking you whether to save the settings appears. Tap on the message to
enable the new settings. Tap to cancel the new settings and return to the previous
settings.
• If there are any errors with the input information, a message asking you whether to
discard changes appears. Tap on the message to discard the changes. Tap to
close the dialog.

SATO FX3-LX Specifications

General

Cutter	Yes
Certification	EN55032, EN55024, EN61000-3-2 / 3-3, EN300 330-2 / -1, EN301 489-1 / -3 / -17, FCC Part15 Subpart B, ICES 003 UL60950-1, CSA C22.2 No.60950-1, IEC/EN60950-1 FCC Part15 Subpart C/E, ISED RSS-Gen, ISED RSS-247, EN 300 328, EN 301 893
Built-in barcodes	AZTECCODE, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN13, EAN8, GS1 COMPOSITE, GS1 DataBar, GS1-128, Industrial 2/5, Interleaved 2/5, Matrix 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Built-in RFID module	No
Maximum resolution	- DPI
Maximum print height	500 mm
Maximum printing width	80 mm
Battery voltage	14.4 V
AC input voltage	100 - 240 V
Battery capacity	1950 mAh
AC input frequency	50 / 60 Hz
Suitable for use in country/location	Europe
Sustainability certificates	ENERGY STAR
Display	LCD
Control type	Touch
Product color	White
Display diagonal	7 \
Display resolution	480 x 800 pixels
International Protection (IP) code	IPX2
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
USB 2.0 ports quantity	4
Connectivity technology	Wired & Wireless
Media thickness	0.14 - 0.19 mm
Maximum roll diameter	105 mm
Storage temperature (T-T)	-5 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 75 %
Cables included	AC
Quantity per pack	1 pc(s)
Languages support	Multi

Weight and Dimensions

Depth	225 mm
Width	132 mm
Height	180 mm
Weight	3000 g
