[Wi-Fi Setting]
322
• The gateway address set here is shared with the settings in [Interface] > [Network] >
[Settings] > [LAN] > [IPv6 (LAN)].
[DNS]
If you have selected [Static] in the [Mode] menu, set the primary address of the DNS server.
The setting range is as follows:
0:0:0:0:0:0:0:0 to ffff:ffff:ffff:ffff:ffff:ffff:ffff:ffff
• You can register only one IP address for the DNS server for IPv6.
• The DNS server address set here is shared with the settings in [Interface] > [Network]
> [Settings] > [LAN] > [IPv6 (LAN)].
[Proxy (Wi-Fi)]
Configure the proxy for Wi-Fi.
The setting items are as follows:
[Enabled]
Enable or disable use of proxy.
• To enable the proxy, [Server] should be set and [Exclude] must contain at least
127.0.0.1 and localhost.
[Server]
Set the name or IP address of the proxy server.
Example: http://192.168.1.11:3128
• Server should be set with a valid name or IP address and port number.
• Hold "." to input a colon (:).
[Exclude]
Set names, IP addresses or domains for the proxy to exclude.
• Exclude must contain at least 127.0.0.1 and localhost.
[Port]
Set the TCP/IP port number.
Roles of Port1 to Port3
In the socket server function of TCP/IP, either of the following connection methods can be used.
The ports to be used and their roles change depending on the connection method and communication
protocol.
Two-port connection
Port1 is used for receiving print data, and Port2 is used for returning the printer status.
To Next Page
