Shihlin electric SC3 Series User Manual

Appendix 1 Parameter table
Appendix 186
Group
Parameter
Number
Name
Setting Range
Default
Page
02-20
P.17
Terminal 3-5 signal
range selection
0: Signal sampling range from 4~20mA.
1
80
1: Signal sampling range from 0～10V.
2: Signal sampling range from 0～5V.
02-21
P.39
Terminal 3-5 maximum
operation frequency
50Hz system:1.00～650.00Hz
50.00Hz
80
60Hz system:1.00～650.00Hz
60.00Hz
02-24
P.184
Terminal 3-5
disconnect selection
0: Off
0
80
1: Inverter decelerates to 0Hz, multi-function digital
output terminal set off alarm
2: Inverter stops immediately, and keypad displays
“AErr” alarm
3: Inverter runs continuously according to the frequency
command before disconnection. Digital output terminal
will set off alarm.
02-25
P.198
Terminal 3-5 minimum
input current/ voltage
0～20.00 mA /V
0.00V
80
02-26
P.199
Terminal 3-5 maximum
input current/ voltage
0～20.00 mA/ V
10.00V
80
02-27
P.196
Percentage
corresponds to terminal
3-5 minimum input
current/ voltage
0%～100.0%
0.0%
80
02-28
P.197
Percentage
corresponds to terminal
3-5 maximum input
current/ voltage
0%～100.0%
100.0%
80
02-52
P.56
Inverter rated current
display level
0~500.00A
According
to model
85
02-61
P.141
Polarity of percentage
corresponds to terminal
3-5 current/ voltage
signal
0~11
0
80
03-00
P.83
Terminal STF input
function
0: STF(Inverter runs forward)
0
90
1: STR(Inverter runs reverse)
2: RL(Multi-speed low speed)
3: RM(Multi-speed medium speed)
4: RH(Multi-speed high speed)
5: Reserved
6: External thermal relay actuate
7: MRS(Stops inverter output immediately)
8: RT(Inverter second function)
9: EXJ(External JOG)
10：STF+EXJ
11：STR+EXJ
12：STF+RT
