Scanning
5-42 ACUSON Cypress™ Operator’s Manual
Table 21 describes the menu options for the TOOLS buttons in CW scanning
mode.
TABLE 21. CW Scanning Tools Functions
Button Description
Image Click [
IMAGE] to open a menu with these options:
Spectral Compression Selects Low, Medium, or High.
Low increases the Dynamic Range and displays more
shades of gray; High decreases the Dynamic Range and dis-
plays fewer shades of gray; Medium falls in between.
Transmit Power Controls the maximum acoustic output of
the transducer. Settings range from 5% to 100% of maximum.
Use the lowest setting consistent with diagnostic quality. The
current mechanical index (
MI) and thermal index (TI) of the
acoustic output setting are displayed with the System Data.
NOTE: Refer to the “Safety, Standards, and Accuracy” section of this
manual, and the AIUM document provided with your system “Medi-
cal Ultrasound Safety” for important information about Acoustic Out-
put.
Colorize Applies a variety of colorized maps overlaying the
CW grayshade image. This may be useful in certain situations
to optimize contrast resolution.
Text Adds text labels to an image. See “Adding Text to an Image” on
page 5-15 for details.
Timer Procedure Timer — A timer is available for all exams. To
access the timer, follow these steps:
1. Press TOOLS and click the [TIMER] button.
2. Select [START] to display the timer.
Start: Starts the timer clock.
Restart: Starts the timer clock once it has been stopped.
Stop: Stops the timer clock.
Off: Stops the timer clock and removes it from the screen.
Cancel: Closes the menu without changing the timer
clock.
