Siemens ACUSON Cypress

Basic Setup
3-10 ACUSON Cypress™ Operator’s Manual
Save The Save options include:
 Save Time Limit: Sets the number of seconds to
be captured when the •
SAVE key is pressed. The
•
SAVE key can be set to capture 4, 8, 16, or 32 sec-
onds of data. •
SAVE will capture only one frame of
the Time-Motion display in M-Mode and one frame
of the spectral display in the Doppler modes.
 QSAVE Cycle Limit: Sets the number of cardiac
cycles to be captured when
Q SAVE is pressed. The
Q SAVE key can be set to capture 1, 2, or 3 cardiac
cycles when the patient’s
ECG is properly displayed
on the screen. When an
ECG is not displayed, the
QSAVE button will capture 2, 4, or 6 seconds of
data. Note that
Q SAVE captures only one frame of
the Time-Motion display in M-Mode and one frame
of the spectral display in the Doppler modes.
 Lock Studies: Sets the status of a study once it is
deactivated. Options include:
Never — Changes can be made to the studies at
any time.
After ## Hours — Use the trackball to place the
cursor in the box and type the number of hours after
which the study will automatically lock.
Once Deactivated — Studies are locked as soon
as they are deactivated.
Stress Echo When Enabled, the captured loops will include the
entire heart cycle (i.e., Full Cycle Capture) instead of
being limited to ~360 ms (systole). Click the checkbox
to enable (the default setting is disabled).
Printer Designates the printer. The Active window displays
the current printer. To install a new printer, click [
NEW
PRINTER
] and select a printer driver.
Eject MO on
Shutdown
Sets the Cypress to eject an MO disk during Shut-
down. To automatically eject an MO disk during the
Shutdown process, click Enabled. To turn automatic
eject off, click Disabled.
TABLE 4. Setup Menu Fields
Field Description
