ACUSON Cypress™ Operator’s Manual 3-9
The Setup Menu
Date and Time Sets the date and time. Note that the time must be
entered in military time using a 24-hour clock.
To change the date and/or time: Place the cursor in
the date and time boxes and type the new settings.
Click the [
SET] button.
24 Hour Clock. Changes the display of time
throughout the system. A check mark in the box
tells the system to display military time. 2:00
PM is
displayed as 14:00:00. To enable the 24-hour clock,
click the checkbox. To disable the 24-hour clock,
click the checkbox again to remove the check.
AM
and
PM time are displayed when the box is not
checked.
Video Out Mode Sets the video out mode. Use
VGA when connecting a
monitor or overhead projector. Use
NTSC when con-
necting a video printer or
VCR. Use PAL for the Euro-
pean video standard. Use the
RGB modes (RGB NTSC
and
RGB PAL) with a color video printer.
TABLE 4. Setup Menu Fields
Field Description
