Extended Administration
103
Configuration files
Each configuration file will be built from a template file containing tags in-
stead of phone-specific parameter values. To create a configuration file,
the Broadworks management system will take the template file as input,
replace the tags with phone-specific values and store using the appropri-
ate device configuration file name. For further information to configure the
download see ! Specify configuration update file, page 87.
Template File
The Broadworks system allows for a number of different template files,
each serving a group of phones. For further information see Broadsoft
Server Administration guide and ! Specify configuration update
file, page 87.
Broadsoft Specific Configuration
Below you will see an example of a possible configuration.
Setting Configuration
System
Terminal Number Matches the user’s Phone Number listed in the Broadsoft
web page.
Terminal Name Blank
Register By Name Off
SIP Routing Server
Outbound Proxy Off
Default OBP Domain Blank
SIP Server Address of the Broadsoft Server (same as web portal ad-
dress).
SIP Registrar Address of the Broadsoft Server (same as web portal ad-
dress).
SIP Gateway Blank
SIP Transport UDP
SIP Realm To match the realm of the group.
SIP User ID To match the user’s Authentication User Name listed in
the Broadsoft web page.
SIP Password To match the user’s Authentication Password listed in the
Broadsoft web page.
SIP Session Timer Off
SIP Session Time Not applicable
