Phone Configurations
241
Phone Configurations
This section identifies the configuration settings to allow the phone to op-
erate in various system environments these include for example:
•HiQ8000
• Broadsoft
• Sylantro
This configuration is a common one dealing with settings generic to all sys-
tems. System specific ones follow.
Common Configuration (Factory Defaults)
Function standard value
Administration password
Password Editor ! page 158
123456
Application DL filename
1
ipphone.app
Audio mode
G711 Preference
Configuration DL filename
Default route 0.0.0.0
DHCP IP assign on
LAN Port Setting Auto
PC Port Setting Auto
VLAN Discovery DHCP
DL server IP address 0.0.0.0
Domain name
FTP account name guest
FTP password
Password Editor ! page 158
123abc
FTP path null
FTP username guest
Gatekeepers 0.0.0.0
Gateway 0.0.0.0
Hold music filename MoHFile
IP routing 0.0.0.0 (all)
Jitter buffer normal
Compression G729
G711 Silence Off
Language English
LDAP server address 0.0.0.0
To Next Page
