Alphabetical Reference
198
Line monitor
• Activate the display to view the functions and values used to run the
! LAN connections at the phone (layout ! page 23).
• The status monitor remains active even during the normal operation of
the optiPoint 410/420 family S V6.0. However, it does not affect the op-
eration of the function keys.
Line Monitor information optiPoint 410
LAN Port 1 (LAN)
LAN Port 2 (PC)
Explanation report:
Line Monitor information optiPoint 420
LAN Port 1 (LAN)
LAN Port 2 (PC)
10 Mb/s Full duplex LED: 9, 11
10 Mb/s Half duplex LED: 9
100 Mb/s Full duplex LED: 9, 10, 11
100 Mb/s Half duplex LED: 9, 10
10 Mb/s Full duplex LED: 5, 7
10 Mb/s Half duplex LED: 5
100 Mb/s Full duplex LED: 5, 6, 7
100 Mb/s Half duplex LED: 5, 6
LED 9 or 5 'on' Connection established
LED 9 or 5 'off' Connection not established
LED 6 or 10 'on' 100 Mb/s connection
LED 6 or 10 'off' 10 Mb/s connection
LED 7 or 11 'on' Full duplex connection
LED 7 or 11 'off' Half duplex connection
10 Mb/s Full duplex LED: 10, 12
10 Mb/s Half duplex LED: 10
100 Mb/s Full duplex LED: 10, 11, 12
100 Mb/s Half duplex LED: 10, 11
10 Mb/s Full duplex LED: 6, 8
10 Mb/s Half duplex LED: 6
100 Mb/s Full duplex LED: 6, 7, 8
100 Mb/s Half duplex LED: 6, 7
