Alphabetical Reference
214
SIP addresses
• Use this function to define the following IP addresses or host names.
• Value range table:
• Editing by phone: IP Number Editor ! page 159 and if DNS is applica-
ble ! page 41 also Text Editor ! page 155.
! page 61 ! page 115
SIP Auto answer
• This setting controls whether or not alerting calls can obey any auto-an-
swer request signalled for the call. Automatic answering will only apply
to the primary line of a Keyset. Mark this option enabled/disabled.
• When you dial a number using the CTI application while “Auto Answer”
is activated, the telephone automatically switches to handsfree mode.
If “Auto Answer” is deactivated, the telephone will ring first and you
must then press the loudspeaker key or lift the handset to dial the num-
ber and set up the connection to the other station.
! page 63 ! page 116
IP address Use
SIP Server IP address or host name and port of the SIP proxy
server (Hipath 8000).
SIP Registrar This field is only used when the phone is in "Server"
routing mode ! page 216. It contains the IP address
or host name and port of the registration server, to
which the phone will send REGISTER messages. Ei-
ther an IP address or a host name may be entered.
With an address entered in the SIP Registrar field,
the phone will register and be able to receive incom-
ing calls, but in order to make outgoing calls it is also
necessary to enter an address into the SIP Server
field (see above).
SIP Gateway
and Port
IP address or host name and port of the SIP gate-
way. E.g. for a hardware box to phone directly into
the public network (conversion of SIP to TDM). SIP
routing has to be set to "Gateway" for this function.
SIP Port Access base IP port for receiving & sending SIP
messages.
RTP Base Port Access base IP port for RTP transport.
Permitted values numeric (with DNS also alphanumeric)
Length max. 15 digits (incl. dots)
(with DNS also 92 digits)
