Alphabetical Reference
194
Layer 2 voice
Can be defined only if the ! Layer 2 support is activated (! Quality of Ser-
vice (QoS)).
! page 58 ! page 117
LAN port settings
• Use this function to define the bandwidth at which the optiPoint 410/
420 family S V6.0 should be run. The required value depends on the
bandwidth that the switch or router supports in the network.
• The PC port can setup in the same way as the LAN port.
• The change will only have effect if you restart the phone.
! page 59 ! page 123
Last Restart
• Use this function to view the date and time of the last restart
! page 96 of the optiPoint 410/420 family S V6.0.
! page 96
LDAP Server IP Address
•If an ! LDAP server is being used, enter the ! IP address of this serv-
er here.
• IP editor in optiPoint 410/420 family S V6.0 ! page 159.
! page 78 ! page 136
LDAP server Port
•If an ! LDAP server is being used, enter the ! Port number here for
communication with this server.
• Valid values: 1 ... 65535.
• Default port is 389
• Number editor in optiPoint 410/420 family S V6.0 ! page 157.
! page 78 ! page 136
Bandwith Use
Automatic in standard case (automatic detection)
10 Mbit/s full in 10 Mbit networks in full duplex
1
process
1 The data can be transmitted and received simultaneously.
10 Mbit/s half in 10 Mbit networks with half duplex
2
process
2 The data can only be transmitted or received.
100 Mbit/s full in 100 Mbit networks in full duplex
1
process
100 Mbit/s half in 100 Mbit networks with half duplex
2
process
