Installing the Phone
Connectors on the bottom of the telephone
entry S economy S economy plus S standard S advance S
1 Ethernet port for LAN connection (optional with PoL
*
)
* Power over LAN:
If power is supplied over the LAN cable, no local power supply is required.
2 Handset connector
3 Connector for a local power supply unit (optional*)
4 - - - Module connector
5 - - Ethernet port for PC
6 - - Headset connector
7 - - - Adapter 1
8 - - - Adapter 2 -
9 -- - -USB-Master
2
1
3
1
2
3
6
4
5
7
8
optiPoint 410 entry optiPoint 410 advance
9
