Installation
21
Starting up the optiPoint 410/420 S V6.0
• Plug the short end of the handset cable into the handset and the other
end into the connector 2 at the bottom of the telephone and feed the
cable through the guide channel in the base unit.
• Using the headset connector:
Plug the jack of the headset cable into connector 6 at the bottom of the
telephone and feed the cable through the guide channel in the base
unit.
• Using optiPoint modules (4):
Mount this device following the instructions in the installation guide
(A31003-H8400-B934-*-6ZD1).
• Using adapter (7, 8 ):
Mount this device following the instructions in the installation guide
(A31003-H8400-B934-*-6ZD1).
• Using an external keyboard:
Plug the keyboard cable into the USB connector 9 at the bottom of the
telephone.
• Using a LAN connection to PC:
Plug the jack of the connection cable into the connector 5 at the bottom
of the telephone.
Only if power not supported by LAN:
– Plug the plug-in power supply unit into the mains.
– Plug the connector 3 at the bottom of the telephone into the plug-in
power supply unit.
• Plug the jack of the LAN cable into the connector 1 at the bottom of the
telephone and connect the cable with LAN.
• Feed the cables through the relief on the back of the housing and fix
them by means of the cable clip.
The optiPoint 410/420 phone is to connect to a Switch. (The phone
is working also on a Hub, but without a guarantee of quality)
The Western plugs of all cable connections must audibly snap into
place.
7
Use only the plug-in power supply unit fitting the optiPoint 410/420:
– GER/IM: AUL:06D1284
– GBR: AUL:06D1287
– USA: AUL:51A4827
