1.2 Configuration options for ET 200pro
The motor starters and their properties can be combined as follows:
• Standard motor starters and high feature motor starters can be combined as desired.
ET 200pro with motor starters
Figure 1-1: ET 200pro with motor starters
ET 200pro with motor starters and electronic modules
Figure 1-2: ET 200pro with motor starters and electronic modules
