ITC Operating mode
5.7 Operating ITC
ITC V3, ITC V3 PRO
Operating Instructions, 03/2024, A5E42761061-AF
121
5.7.2.2 Starting a connection
Overview
You can connect to a server From the Industrial Thin Client according to the configured
connection settings. The following connection types are supported:
• RDP
• Sm@rtServer/VNC
• WinCC OA
• Web: In addition to the web connection settings, web settings are required for the
browser that displays the web connection.
Limited number of browser instances
A maximum of 5 browser instances can be started at the same time. When you open a
sixth browser instance, an error message appears.
You can open the Web browser separately to establish a connection of any kind to the
Internet regardless of the maximum number of browser instances and client-server
connections.
-server connections
-server connections can be started at the same time. If a 6th
connection is activated, an error message appears
Procedure for client-server connection
Proceed as follows to establish a client-server connection:
1. Touch the "Favorites" icon in the taskbar.
2. Select a client-server connection.
The configured connection to the server or system network will be started.
Procedure for web browser
Proceed as follows to establish a connection to the Internet or an intranet:
1. Select the "Web browser" menu command in the taskbar of the Start menu. The web
browser will open.
The IP address of the device is stored as the home page. The home page displays
important device data and network settings.
2. Specify a valid Internet address in the address line of the web browser.
