SINUMERIK operating mode
6.2 Networking
ITC V3, ITC V3 PRO
162 Operating Instructions, 03/2024, A5E42761061-AF
6.2.4.8 Run-up of the panel
Messages during booting
Messages during run-up
While the ITC runs up, a progress indicator is displayed with messages showing the current
status after the BIOS has been loaded and before the operating system starts. While the IP
address is being determined via DHCP and the TFTP is being downloaded (boot image), a
progress bar indicates that run-up of the ITC is not yet complete, or that a fault has occurred.
The figure below shows the structure of these messages:
You can see the current boot phase below the progress bar. If a fault occurs, you can call
further information by touching the "F1" field.
