ITC Operating mode
5.5 Assigning device parameters
ITC V3, ITC V3 PRO
Operating Instructions, 03/2024, A5E42761061-AF
107
Setting the desktop orientation
This setting is available from firmware version V3.2.2.0 onwards.
Under "Desktop orientation", select the entry "Landscape (0°)" or "Portrait (90°)" depending on
the mounting position of your device.
Setting up a background image
Under "Background image", specify a graphic file to be displayed as the background image.
Use the "Browse" button to select a graphic file on the connected USB drive.
Required properties of background images
Format: PNG, JPG, JPEG
File size: max. 5 MB
Resolution: Maximum 1920 x 1080 for ITC2200
Colors: Maximum 16777216
Display of the background image
The background image is always stretched to fit the screen resolution, even when this
distorts it and grossly enlarges it.
Therefore, the background image should have exactly the same width x height as the
screen resolution, for example 1280 x 800, or at least the same proportions, for example
640 x 400.
Restoring the factory settings
The background image is restored.
See also
Structure and functions of the taskbar (Page 119)
Starting a connection (Page 121)
5.5.10 The "Programs" submenu
Introduction
Additional, configurable application programs (software applications) can run on the
Industrial Thin Client. The web browser is currently the only application.
The following figure shows the web browser settings in the Start menu "Configuration >
Applications".
