Siemens SIMATIC ITC1200 V3 - Service and Diagnostics; Operation of the ITC Main Menu

SINUMERIK operating mode
6.2 Networking
ITC V3, ITC V3 PRO
146 Operating Instructions, 03/2024, A5E42761061-AF
Example:
[Station]
maxhostindex=2
/* Number of nodes that are defined under
[host 1] and [host 2].
mcpIndex=192
tcuIndex=1
eksIndex=0
[host_1]
Address=192.168.214.1
/* Address of the NCU to which the
connection is established during booting.
[host_2]
Address=157.163.230.202
/* Address of the PC
password=123456
/* Password of the VNC server on the PC
Switching over between the nodes
With the menu back key + MENU SELECT, the following actions are triggered:
• The ITC name is displayed in the header of the displayed window, e.g. ITC1.
• A selection list for connecting to the other nodes is displayed on the ITC.
6.2.4 Service and diagnostics
6.2.4.1 Operation of the ITC main menu
Displaying the ITC menu
• With touch screens: Simultaneously touch the left-hand and right-hand lower corner of
the active display area with one finger at a time.
• With connected keyboard: Press the menu back key and the <MENU SELECT> key
