Overview
1.3 Layout of the devices
ITC V3, ITC V3 PRO
24 Operating Instructions, 03/2024, A5E42761061-AF
1.3.3 Interfaces
The following figures show the interfaces of the ITC V3 devices.
Built-in units
PRO devices
Functional grounding connection
X1 P1 PROFINET (LAN), 10/100/1000 MBit
X80 power supply connector
X1 P2 LAN, 10/100/1000 MBit
B1 "Factory settings" button
