ITC V3, ITC V3 PRO
Operating Instructions, 03/2024, A5E42761061-AF
207
Markings and symbols
B.1 Safety-relevant symbols
The following table describes symbols that can be added to your SIMATIC device, to its
packaging or to an enclosed document in addition to the symbols described in the manuals.
General danger sign Caution / Attention
You must following the operating instructions. The operating instructions
contain information on the type of the potential hazard and enable you
to identify risks and implement countermeasures.
DIN ISO 7000 No. 0434B
Attention, only relevant for modules with Ex approval
May be installed by qualified electricians only
Mechanical load for HMI devices
Connection cables must be designed for the ambient temperature
EMC-compliant installation
No mounting or pulling & plugging under voltage
Dangerous electrical voltage for 230V modules ANSI Z535.2
Protection class III, supply only with protective low voltage (SELV/PELV) IEC 60417-1-5180
"Class III equipment"
