Siemens SIMATIC ITC1200 V3 - Itc1900;2200;2400 V3 (Pro)

Technical specifications
8.7 Technical specifications
ITC V3, ITC V3 PRO
Operating Instructions, 03/2024, A5E42761061-AF
201
8.7.2 ITC1900/2200/2400 V3 (PRO)
Weight
ITC1900 V3
ITC2200 V3
ITC2400 V3
Weight without packaging, with
power supply plug, mounting clips
and strain relief plate
6.1 kg
7.2 kg
8.7 kg
Weight of PRO devices for support arm (not extendable, flange top) and for pedestal
(extendable, flange bottom)
ITC1900 V3 PRO
ITC2200 V3 PRO
ITC2400 V3 PRO
Weight without packaging
7.4 kg
8.5 kg
10.1 kg
Weight of PRO devices for support arm (extendable, round tube)
ITC1900 V3 PRO
ITC2200 V3 PRO
ITC2400 V3 PRO
Weight without packaging
7.2 kg
8.1 kg
10.0 kg
Display
ITC1900 V3 (PRO)
ITC2200 V3 (PRO)
ITC2400 V3 (PRO)
Type
LCD TFT
Display diagonal
18.5''
21.5''
23.8''
Active display area
409.0 x 230.0 mm
476.0 x 267.8 mm
527.0 x 296.5 mm
Resolution HD devices
1366 x 768 pixels
-
-
Resolution Full HD devices
1920 x 1080 pixels
1920 x 1080 pixels
1920 x 1080 pixels
Possible colors
Up to 16 million
Brightness control
Yes, value range 1 to 100
Backlighting
LED
Half Brightness Life time (MTBF 1)
50000 h
30000 h
30000 h
Pixel error class in accordance with
ISO 9241-307
I
1
MTBF: Operating hours after which the maximum brightness is reduced by half compared to the original value. The
MTBF increases with reduced brightness or with the use of a screen saver on the server.
Input device
ITC1900 V3 (PRO)
ITC2200 V3 (PRO)
ITC2400 V3 (PRO)
Touch screen
Yes, projective-capacitive
