ITC Operating mode
5.5 Assigning device parameters
ITC V3, ITC V3 PRO
110 Operating Instructions, 03/2024, A5E42761061-AF
Depending on the keyboard you are using, it may be necessary to press the Shift key to
access the "+" and "
-" keys. In this case, use <Control><Shift><+> to enlarge the display
and <Control><Shift><-> to reduce it.
5.5.11 Remote configuration
Introduction
Remote configuration enables remote configuration and remote update of a SIMATIC
Industrial Thin Client from a PC that is connected to the Industrial Thin Client via a network.
Functions
You can perform the following actions from a central PC for an Industrial Thin Client:
• Edit configuration settings
• Back up and restore the configuration
• Identifying a device
• Change IP addresses
• Update firmware
• Restart devices
Remote access
During remote access, you perform the corresponding configuration functions directly on the
Industrial Thin Client, i.e. the user interface corresponds to the user interface on the
Industrial Thin Client itself.
The remote access to the Industrial Thin Client is made via an encrypted connection in HTML5
format, which means access must be made with a Web browser that supports HTML5 and
encrypted connections (https).
Requirement
• The Industrial Thin Client and the PC for remote access are located in the same subnet.
• The "Remote configuration" option is activated in the system settings of the Industrial Thin
Client (Page 87).
• A Web browser that supports HTML5 and encrypted connections is installed on the PC.
Procedure
1. Open the Web browser.
2. Enter the IP address or device name of the Industrial Thin Client that you want to configure
in the address line of the Web browser.
If a message appears regarding the certificate for the encrypted connection, confirm the
message.
