Overview
1.3 Layout of the devices
ITC V3, ITC V3 PRO
Operating Instructions, 03/2024, A5E42761061-AF
17
1.3 Layout of the devices
1.3.1 ITC V3 built-in units
The following figures show the structure of the Industrial Thin Clients using an example of
the SIMATIC ITC1900 V3 built-in units with Siemens logo.
Front view and side view
①
Capacitive touch screen
②
Recesses for mounting clips
③
Mounting seal
Bottom view
①
"Factory settings" button
②
Interfaces
③
Recesses for mounting clips
