SINUMERIK operating mode
6.1 SINUMERIK commissioning
ITC V3, ITC V3 PRO
128 Operating Instructions, 03/2024, A5E42761061-AF
After successful first commissioning, the SINUMERIK server screen is displayed.
Result
The first commissioning has been completed and the operating mode SINUMERIK has been
defined. In the future, the device starts in SINUMERIK operating mode and the first
commissioning dialogs are no longer displayed.
The further description of the SINUMERIK operating mode can be found in the following
section.
To recommission, you must reset the device to factory settings or update the firmware.
Reset to factory settings in SINUMERIK operating mode
1. Switch off power to the device.
2. Press and hold the "Factory settings" button on the device and switch on the power supply
of the device again. The device restarts.
Use a sturdy blunt tool made of non-conductive material with a diameter of approximately
5 mm. The "Factory settings" button is next to the interface X1 P1 PROFINET (LAN).
3. Press and hold the "Factory settings" button until the boot procedure has finished and the
first commissioning dialog is displayed.
4. Select the "SINUMERIK" operating mode in the first commissioning dialog.
-commissioning in the SINUMERIK operating mode
When you reset the Industrial Thin Client using the "Factory settings" button, some
SINUMERIK settings, such as the rotation of the display, are retained.
Updating firmware in SINUMERIK operating mode
1. Switch off power to the device.
2. Press and hold the "Factory settings" button on the device and switch on the power supply
of the device again. The device restarts.
Use a sturdy blunt tool made of non-conductive material with a diameter of approximately
5 mm. The "Factory settings" button is next to the interface X1 P1 PROFINET (LAN).
3. Press and hold the "Factory settings" button until the boot procedure has finished and the
first commissioning dialog is displayed.
4. Select ITC operating mode and follow the instructions of the Setup wizard.
5. Connect a USB drive using an update file ".upd" with the device USB interface. The firmware
version of the update file must be more recent than the firmware version on the device.
6. Choose "Settings > System" in the taskbar.
7. In the "Device configuration" area, use the "Update" button to select the update file "*.upd".
The device restarts and the first commissioning dialog is displayed.
8. Select the "SINUMERIK" operating mode in the first commissioning dialog.
