Data formats and data records
SIMOCODE pro
B-42 GWA 4NEB 631 6050-22 DS 03
B.18 Data record 202 - Acyclic receive
Description
The acyclic receive data can be used for any functions. The receive data is
available as device-internal outputs (sockets).
Byte.Bit Designation Type Information
0.0 Reserved Byte[4]
BU1 BU2
4.0 Acyclic receive - Bit 0.0 Bit
4.1 Acyclic receive - Bit 0.1 Bit
4.2 Acyclic receive - Bit 0.2 Bit
4.3 Acyclic receive - Bit 0.3 Bit
4.4 Acyclic receive - Bit 0.4 Bit
4.5 Acyclic receive - Bit 0.5 Bit
4.6 Acyclic receive - Bit 0.6 Bit
4.7 Acyclic receive - Bit 0.7 Bit
5.0 Acyclic receive - Bit 1.0 Bit
5.1 Acyclic receive - Bit 1.1 Bit
5.2 Acyclic receive - Bit 1.2 Bit
5.3 Acyclic receive - Bit 1.3 Bit
5.4 Acyclic receive - Bit 1.4 Bit
5.5 Acyclic receive - Bit 1.5 Bit
5.6 Acyclic receive - Bit 1.6 Bit
5.7 Acyclic receive - Bit 1.7 Bit
6.0 Acyclic receive - Analog value Word
Table B-19: Data record 202 - Acyclic receive
