A.3 Socket assignment table - digital
This table contains all assignment numbers (No.) of the sockets (digital). You
only need these assignment numbers if you, for example, use a user
program to fill data records and write these back.
No. Designation Designation Information
0 Static level Not connected BU1 BU2
1 Fixed level‚ 0 BU1 BU2
2 Fixed level‚ 1 BU1 BU2
3 Reserved
4 Reserved
5 Reserved
6 Reserved
7 Reserved
8 Basic unit (BU) BU Test/Reset button BU1 BU2
9 BU Input 1 BU1 BU2
10 BU Input 2 BU1 BU2
11 BU Input 3 BU1 BU2
12 BU Input 4 BU1 BU2
13 Reserved
14 Reserved
15 Reserved
16 Digital module DM DM1 - Input 1 DM1
17 DM1 - Input 2 DM1
18 DM1 - Input 3 DM1
19 DM1 - Input 4 DM1
20 DM2 - Input 1 DM2
21 DM2 - Input 2 DM2
22 DM2 - Input 3 DM2
23 DM2 - Input 4 DM2
24 DM-FL sensor channel 1 Y12 DM-FL
25 DM-FL sensor channel 2 Y22 DM-FL
26 Reserved
27 Reserved
28 Reserved
29 Reserved
30 Reserved
31 Reserved
32 Operator panel OP/OPD OP Test/Reset button OP OPD
33 OP Button 1 OP OPD
34 OP Button 2 OP OPD
35 OP Button 3 OP OPD
36 OP Button 4 OP OPD
37 Reserved
Table A-3: Socket assignment table - digital
