Data formats and data records
SIMOCODE pro
B-26 GWA 4NEB 631 6050-22 DS 03
B.12 Data record 131 - Basic device parameters 2 (plug )
Byte.
Bit
Designation
(PRM group)
Type Range De-
fault
Note Informa-
tion
0.0 Reserved Byte[4]
4.0 Byte parameters (40)
4.0 BU - Output 1 Byte 0 .. 255 0 BU1 BU2
5.0 BU - Output 2 Byte 0 .. 255 0 BU1 BU2
6.0 BU - Output 3 Byte 0 .. 255 0 BU1 BU2
7.0 Reserved Byte 0
8.0 OP - LED green 1 Byte 0 .. 255 0 OP OPD
9.0 OP - LED green 2 Byte 0 .. 255 0 OP OPD
10.0 OP - LED green 3 Byte 0 .. 255 0 OP OPD
11.0 OP - LED green 4 Byte 0 .. 255 0 OP OPD
12.0 OP - LED yellow 1 Byte 0 .. 255 0 OP
13.0 OP - LED yellow 2 Byte 0 .. 255 0 OP
14.0 OP - LED yellow 3 Byte 0 .. 255 0 OP
15.0 Reserved Byte 0
16.0 Cyclic send - Bit 0.0 Byte 0 .. 255 105 Default: Status -
ON<
BU1 BU2
17.0 Cyclic send - Bit 0.1 Byte 0 .. 255 106 Default: Status -
OFF
BU1 BU2
18.0 Cyclic send - Bit 0.2 Byte 0 .. 255 107 Default: Status -
ON>
BU1 BU2
19.0 Cyclic send - Bit 0.3 Byte 0 .. 255 128 Default: Event -
Overload
operation
BU1 BU2
20.0 Cyclic send - Bit 0.4 Byte 0 .. 255 110 Default: Status -
Interlocking time
active
BU1 BU2
21.0 Cyclic send - Bit 0.5 Byte 0 .. 255 120 Default: Status -
Remote mode
BU1 BU2
22.0 Cyclic send - Bit 0.6 Byte 0 .. 255 96 Default: Status -
General fault
BU1 BU2
23.0 Cyclic send - Bit 0.7 Byte 0 .. 255 97 Default: Status -
General warning
BU1 BU2
24.0 Cyclic send - Bit 1.0 Byte 0 .. 255 0 BU1 BU2
25.0 Cyclic send - Bit 1.1 Byte 0 .. 255 0 BU1 BU2
26.0 Cyclic send - Bit 1.2 Byte 0 .. 255 0 BU1 BU2
27.0 Cyclic send - Bit 1.3 Byte 0 .. 255 0 BU1 BU2
28.0 Cyclic send - Bit 1.4 Byte 0 .. 255 0 BU1 BU2
29.0 Cyclic send - Bit 1.5 Byte 0 .. 255 0 BU1 BU2
30.0 Cyclic send - Bit 1.6 Byte 0 .. 255 0 BU1 BU2
31.0 Cyclic send - Bit 1.7 Byte 0 .. 255 0 BU1 BU2
32.0 Acyclic send - Bit 0.0 Byte 0 .. 255 0 BU1 BU2
33.0 Acyclic send - Bit 0.1 Byte 0 .. 255 0 BU1 BU2
Table B-13: Data record 131 - Basic device parameters 2
