Siemens SIMOCODE pro System Manual

Technical data
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
D-27
D.8 Typical reaction times
D.8.1 SIMOCODE pro C device series
Table D-15: Typical reaction times for SIMOCODE pro C device series
D.8.2 SIMOCODE pro V
1)
device series
1) Based upon a typical hardware set-up: Basic unit + current measuring module
+ 2 expansion modules
Table D-16: Typical reaction times for SIMOCODE pro V device series
Reaction time = inputs conversion time + internal processing time + outputs
conversion time
Example:
You wish to switch a relay output of the basic unit via PROFIBUS when the
"remote" bit is set:
•SIMOCODEproC:
Reaction time = 30 ms + 30 ms + 10 ms = 70 ms
•SIMOCODEproV:
Reaction time = 5 ms + 5 ms + 10 ms = 20 ms
Time: Inputs Time: Processing Time: Outputs
Basic unit Set delay time
30 ms
10 ms
Thermistor 400 ms
PROFIBUS 30 ms 30 ms
Current measuring 200 ms
Internal earth fault 300 ms - 600 ms +
Set delay
Time: Inputs Time: Processing Time: Outputs
Basic unit Set delay time
5 ms
10 ms
Thermistor 400 ms
PROFIBUS 5 ms 5 ms
Current measuring 300 ms
Voltage measurement 300 ms
Active power/cos phi 1000 ms
Internal earth fault 300 ms - 600 ms +
Set delay
Earth-fault module/
external earth fault
300 ms - 500 ms +
Set delay
Digital module (24 V) 15 ms + delay 25 ms
Digital module
(110 V - 240 V)
50 ms + delay 25 ms
Analog module 150 ms 25 ms
Temperature module 500 ms
DM-F Local ≤ 75 ms + delay time 30 ms
DM-F PROFIsafe 15 ms + delay 30 ms
