Data formats and data records
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
B-45
B.21 Assignment of cyclic receive and send data for
predefined control functions
B.21.1 Overload relay
Table B-22: Assignment of cyclic receive/send data, overload relay
*) for SIMOCODE pro V, basic type 1 only
Cyclic receive data
Bit 0.0 Not connected
Bit 0.1 Not connected
Bit 0.2 Not connected
Bit 0.3 Further function blocks -> Standard functions -> Test/Reset -> Test 1 - Input
Bit 0.4 Further function blocks -> Standard functions -> Emergency start -> Emergency start - Input
Bit 0.5 Not connected
Bit 0.6 Further function blocks -> Standard functions -> Test/Reset -> Reset 1 - Input
Bit 0.7 Not connected
Bit 1.0 Not connected
Bit 1.1 Not connected
Bit 1.2 Not connected
Bit 1.3 Not connected
Bit 1.4 Not connected
Bit 1.5 Not connected
Bit 1.6 Not connected
Bit 1.7 Not connected
Byte 2/3 *) (analog value) Not connected
Cyclic send data
Bit 0.0 Not connected
Bit 0.1 Not connected
Bit 0.2 Not connected
Bit 0.3 Event - Pre-warning overload (I>115 %)
Bit 0.4 Not connected
Bit 0.5 Not connected
Bit 0.6 Status - General fault
Bit 0.7 Status - General warning
Bit 1.0 Not connected
Bit 1.1 Not connected
Bit 1.2 Not connected
Bit 1.3 Not connected
Bit 1.4 Not connected
Bit 1.5 Not connected
Bit 1.6 Not connected
Bit 1.7 Not connected
Byte 2/3 (analog value) Maximum current I_max
Byte 4/5 *) (analog value) Not connected
Byte 6/7 *) (analog value) Not connected
Byte 8/9 *) (analog value) Not connected
