Siemens SIMOCODE pro System Manual

Data formats and data records
SIMOCODE pro
B-56 GWA 4NEB 631 6050-22 DS 03
B.21.12 Positioner
Table B-33: Assignment of cyclic receive/send data, positioner
*) for SIMOCODE pro V, basic type 1 only
Cyclic receive data
Bit 0.0 Device parameters -> Motor control -> Control stations -> PLC/PCS [DP] -> CLOSED
Bit 0.1 Device parameters -> Motor control -> Control stations -> PLC/PCS [DP] -> STOP
Bit 0.2 Device parameters -> Motor control -> Control stations -> PLC/PCS [DP] -> OPEN
Bit 0.3 Further function blocks -> Standard functions - Test/Reset -> Test 1 - Input
Bit 0.4 Further function blocks -> Standard functions -> Emergency start -> Emergency start - Input
Bit 0.5 Device parameters -> Motor control -> Control stations -> Mode selector S1
Bit 0.6 Further function blocks -> Standard functions -> Test/Reset -> Reset 1 - Input
Bit 0.7 Not connected
Bit 1.0 Not connected
Bit 1.1 Not connected
Bit 1.2 Not connected
Bit 1.3 Not connected
Bit 1.4 Not connected
Bit 1.5 Not connected
Bit 1.6 Not connected
Bit 1.7 Not connected
Byte 2/3 *) (analog value) Not connected
Cyclic send data
Bit 0.0 Status - ON < (Closed)
Bit 0.1 Status - OFF (Stop)
Bit 0.2 Status - ON > (Open)
Bit 0.3 Event - Pre-warning overload (I>115 %)
Bit 0.4 Status - Interlocking time active
Bit 0.5 Status - Remote mode
Bit 0.6 Status - General fault
Bit 0.7 Status - General warning
Bit 1.0 Status - Positioner runs in open direction
Bit 1.1 Not connected
Bit 1.2 Status - Positioner runs in close direction
Bit 1.3 Not connected
Bit 1.4 Not connected
Bit 1.5 Not connected
Bit 1.6 Not connected
Bit 1.7 Not connected
Byte 2/3 (analog value) Maximum current I_max
Byte 4/5 *) (analog value) Not connected
Byte 6/7 *) (analog value) Not connected
Byte 8/9 *) (analog value) Not connected
