Siemens SIMOCODE pro - Current Measuring Module (Bus Connection) 3 UF7103, 20 a to 200 a

Dimension drawings
SIMOCODE pro
C-6 GWA 4NEB 631 6050-22 DS 03
C.2.4 Current measuring module (bus connection)
3UF7103, 20 A to 200 A
Fig. C-6: Current measuring module (bus connection) 3UF7103, 20 A to 200 A
120
95
37 17
9
79
95
119
7
47
140
5
84
