D.6 Technical data of the operator panels
D.6.1 Technical data of the operator panel
Table D-12: Technical data of the operator panels
Mounting Installation in a switchgear cabinet door or in a front panel, with
IP54 system interface cover.
Display
•Red/green/yellow "DEVICE" LED • Red: Blocked
•Green:
•Flashing green:
•Yellow:
•OFF:
"Function test was negative, device is
blocked"
"Ready for operation"
"No connection to basic unit"
"Memory module or addressing plug
detected"
"No control supply voltage"
•Green "BUS" LED •Continuous light:
•Flashing:
"Communication with PLC/PCS"
"Baud rate recognized/communication
with PC/programming device"
•Red "GEN. FAULT" LED •Continuous light/
flashing:
"Feeder fault", e.g. overload tripping
•3 yellow LEDs / 4 green LEDs For freely assigning any status signals
Buttons
•Test/Reset •Resetting the device after tripping
•Function test (system self-test)
•Operation of memory module, addressing plug
•Control buttons •Control of the motor feeder, freely assignable
System interfaces
•Front For connecting a memory module, an addressing plug or a PC
cable for parameterization purposes
•Rear For connecting a cable to the basic unit or the expansion
module

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
