Siemens SIMOCODE pro System Manual

Technical data
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
D-23
D.6.2 Technical data of the operator panel with display
Table D-13: Technical data of the operator panel with display
Mounting Installation in a switchgear cabinet door or in a front panel,
with IP54 system interface cover.
Display
•Red/green/yellow "DEVICE" LED •Red: Blocked
•Green:
•Flashing green:
•Yellow:
•OFF:
"Function test was negative, device is
blocked"
"Ready for operation"
"No connection to basic unit"
"Memory module or addressing plug
detected"
"No control supply voltage"
•Green "BUS" LED •Continuous light:
•Flashing:
"Communication with PLC/PCS"
"Baud rate recognized/communication
with PC/programming device"
•Red "GEN. FAULT" LED •Continuous light/
flashing:
"Feeder fault", e.g. overload tripping
•4 green LEDs For freely-assigning any status signals (preferably for feedback
on the switching state, e.g. ON, OFF, LEFT, RIGHT)
Display Graphic display of current measured values, operating and
diagnostics data or status information.
Buttons
•Control buttons •Control of the motor feeder, freely assignable
•Arrow keys •Navigation in the display menu
•Softkeys •Various functions, depending upon the menu, e.g. test,
reset, operation of memory module and addressing plug
System interfaces
•Front For connecting a memory module, an addressing plug or a PC
cable for parameterization purposes.
•Rear Connection to the basic unit or expansion module

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
