Important information
SIMOCODE pro
xii GWA 4NEB 631 6050-22 DS 03
Scope of application
This manual is applicable to the listed SIMOCODE pro system components.
It contains a description of the components applicable at the time of printing
the manual. We reserve the right to include updated information about new
components or new versions of components in a product information.
Definitions
• When "SIMOCODE pro" is referred to, both the "SIMOCODE pro C" and the
"SIMOCODE pro V" series are meant.
SIMOCODE pro response tables
Specific responses (deactivated, signaling, warning, tripping) can be
parameterized for various SIMOCODE pro functions, such as overload.
These are always displayed in tabular form:
• "X" = Applicable
• "-" = Not applicable
• Preset values are underlined.
Short description of the responses:
• Tripping: The contactor controls QE* are tripped. A fault message is
generated which is available as a diagnosis via PROFIBUS DP. The fault
message and the device-internal signal remain on until the appropriate
amount of time has elapsed or the cause of the fault has been eliminated and
acknowledged.
• Warning: In addition to the device-internal signal, a warning signal is
generated that is available as a diagnosis via PROFIBUS DP.
• Signaling: Only a device-internal signal is generated, which can be further
processed as required.
• Deactivated: The appropriate function is switched off, no signals are
generated.
A delay time can also be set for specific responses.
Response Function 1 Function 2 Function 3
Tripping - X X
Warning X
X-
Signaling X X -
Deactivated X X X
Delay 0 - 25.5 s - -
