Siemens SIMOCODE pro System Manual

Monitoring functions
SIMOCODE pro
GWA 4NEB 631 6050- 22 DS 03
5-5
5.2 Current limit monitoring
5.2.1 Description
Current limit monitoring is used for process monitoring, independent of
overload protection.
SIMOCODE pro supports two-phase monitoring of the motor current for
freely-selectable upper and lower current limits. The response of
SIMOCODE pro when a pre-warning or trip level has been reached can be
freely parameterized and delayed.
Motor current measurement is carried out via current measuring modules or
current/voltage measuring modules.
Fig. 5-3: "Current Limits" function block
Trip level: I>
1)
Response when I>
Delay when I>
Warning level: I>
Response when I>
Delay when I>
Trip level: I<
2)
Response when I<
Delay when I<
Warning level: I<
Response when I<
Delay when I<
Hysteresis
Event
Event
Event
See
Table 5-3
See
Table 5-4
See
Table 5-5
See
Table 5-6
Current limits
- Trip level I>
Event
- Warning level I>
- Trip level I<
- Warning level I<
Tripping
QE1
QE2
QE3
QE4
QE5
Current I_max from
Current measuring
(Current or
module or
Current/voltage
measuring module)
1) Upper limit
2)
Lower limit
