Siemens SIMOCODE pro System Manual

Communication
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
12-17
12.5 Integration of SIMOCODE pro in the DP master systems
12.5.1 Slave operating modes
The following table shows an overview of the slave operating modes which
SIMOCODE pro can be operated with on the class 1 master:
Table 12-8: Slave operating modes of SIMOCODE pro
12.5.2 Preparing the data transfer
In order to communicate with the class 1 master (PLC), a connection
according to Table 12-8: Slave operating modes of SIMOCODE pro must be
present and the PROFIBUS-DP address must be configured.
See Chapter 14.2.2 "Setting the PROFIBUS DP address" for more
information about setting the address.
SIMOCODE pro
connected as:
Class 1 master
DP master
manufacturer-
independent,
without DPV1 alarms
DP master
manufacturer-
independent,
with DPV1 alarms
S7 master
•DPV1 slave
via GSD
•Cyclic data
exchange
•Standard
diagnostics
• Status information
• Parameterization
during startup (only
BU1)
• Acyclic writing and
reading of DPV1
data records (if
supported by the
master)
•Cyclic data
exchange
• Standard
diagnostics
• Status information
• Process and
diagnostic alarm
• Parameterization
during startup (only
BU1)
• Acyclic writing and
reading of DPV1
data records
• Cyclic data
exchange
• Standard
diagnostics
• Status information
• Process and
diagnostic alarm
• Parameterization
during startup (only
BU1)
• Acyclic writing and
reading of DPV1
data records
• S7 slave via
OM
SIMOCODE pro
— — • Cyclic data
exchange
• Standard
diagnostics
• Process and
diagnostic alarm
• Parameterization
during startup
• Acyclic writing and
reading of DPV1
data records
