Siemens SIMOCODE pro

Dimension drawings
SIMOCODE pro
C-8 GWA 4NEB 631 6050-22 DS 03
C.3 Current/voltage measuring modules
C.3.1 Current/voltage measuring module (through-hole converter)
3UF7110, 0.3 A to 3 A,
3UF7111, 2.4 A to 25 A
Fig. C-8: Current measuring module (through-hole converter) 3UF7110, 0.3 A to 3 A
3UF7111, 2.4 A to 25 A
7 11
21
45
85
5 31
66
