Technical data
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
D-21
D.5.7 Technical data of the temperature module
Table D-11: Technical data of the temperature module
Mounting Snap-on mounting onto 35 mm standard mounting rails or
screw attachment via additional plug-in lugs
Display
•Green "READY" LED •Continuous light: "Ready for operation"
•Flashing: "No connection to basic unit"
System interfaces For connecting to a basic unit, an additional expansion
module, a current measuring module or a current/voltage
measuring module or the operator panel
Sensor circuit
Conversion time 500 ms
Type of connection 2 or 3-wire connection
Typical sensor current:
•PT100 1 mA (typical)
•PT1000/KTY83/KTY84/NTC 0.2 mA (typical)
Open circuit detection/short-circuit
detection/measuring range:
•PT100/PT1000 Open circuit, short circuit; measuring range: -50 °C - +500 °C
•KTY83-110 Open circuit, short circuit; measuring range: -50 °C - +175 °C
•KTY84 Open circuit, short circuit; measuring range: -40 °C - +300 °C
•NTC Short circuit; measuring range: +80 °C - +160 °C
Measuring accuracy at an ambient
temperature of 20 °C (T20)
<+
2 K
Deviation due to ambient
temperature (as % of measuring
range)
0.05 per K deviation from T20
Isolation of the inputs to the
device electronics
No
Connection:
•Tightening torque TORQUE: 7 LB.IN - 10.3 LB.IN
0.8 Nm - 1.2 Nm
•Connection cross sections:
- Solid 2x 0.5 mm
2
- 2.5 mm
2
/ 1x 0.5 mm
2
- 4 mm
2
2 x AWG 20 to 14/1 x AWG 20 to 12
- Finely stranded, with end sleeve 2x 0.5 mm
2
- 1.5 mm
2
/ 1x 0.5 mm
2
- 2.5 mm
2
2 x AWG 20 to 16/1 x AWG 20 to 14
