Technical data
SIMOCODE pro
D-10 GWA 4NEB 631 6050-22 DS 03
D.5 Technical data of the expansion modules
D.5.1 Technical data of the digital modules
Mounting Snap-on mounting onto 35 mm standard mounting rails or
screw attachment via additional plug-in lugs
Display
•Green "READY" LED •Continuous light: "Ready for operation"
•Flashing: "No connection to basic unit"
System interfaces For connecting to a basic unit, an additional expansion
module, a current measuring module or a current/voltage
measuring module or the operator panel
Control circuit
Rated insulation
voltage U
i
300 V (for Degree of Pollution 3)
Rated impulse withstand voltage
U
imp
4 kV
Relay outputs
•Number
•Function
•Stipulated short-circuit protection
for auxiliary contacts (relay
outputs)
•Rated uninterrupted current
•Rated switching capacity
2 monostable or bistable relay outputs (depending on version)
Isolated NO contacts (NC contact response parameterizable
via internal signal conditioning), relay outputs all with common
ground, freely-assignable to control functions (e.g. network,
star or delta contactor or operating state status information).
•Fuse links, operating class gL/gG 6 A, quick-response 10 A
(IEC 60947-5-1)
•Miniature circuit breaker 1.6 A, C-characteristic
(IEC 60947-5-1)
•Miniature circuit breaker 6 A, C-characteristic (I
k
< 500 A)
5 A
6 A at max. +50 °C
AC-15 6 A/24 V AC 6 A/120 V AC 3 A/230 V AC
DC-13 2 A/24 V DC 0.55 A/60 V DC 0.25 A/125 V DC
Inputs (binary) 4 externally supplied, isolated inputs (24 V DC or 110 V - 240 V
AC/DC, depending on version), with common ground for
measuring process signals (e.g. local control station, key-
operated switches, limit switches, ...), freely-assignable to
control functions.
•24 V DC
Cable lengths (single)
Input characteristic
300 m
Type 2 according to EN 61131-2
•110 V - 240 V AC/DC
Cable lengths (single)
Input characteristic
200 m (cable capacitance 300 nF/km)
—
