Siemens SIMOCODE pro System Manual

Technical data
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
D-11
Table D-5: Technical data of the expansion modules
Connection removable terminal block with screw connection
•Tightening torque TORQUE: 7 LB.IN - 10.3 LB.IN
0.8 Nm - 1.2 Nm
•Connection cross sections:
- Solid 2x 0.5 mm
2
- 2.5 mm
2
/ 1x 0.5 mm
2
- 4 mm
2
2 x AWG 20 to 14/1 x AWG 20 to 12
- Finely stranded, with end sleeve 2x 0.5 mm
2
- 1.5 mm
2
/ 1x 0.5 mm
2
- 2.5 mm
2
2 x AWG 20 to 16/1 x AWG 20 to 14

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
