Data formats and data records
SIMOCODE pro
B-12 GWA 4NEB 631 6050-22 DS 03
B.8 Data record 92 - Device diagnostics
Byte.Bit Designation Information DP
Diagn.
*)
Error No.
***)
0.0 Reserved
1.0 Status information
- General
Status - General fault BU1 BU2
1.1 Status - General warning BU1 BU2
1.2 Status - Device BU1 BU2
1.3 Status - Bus BU1 BU2
1.4 Status - PLC/PCS BU1 BU2
1.5 Status - Motor current flowing IM UM
1.6 Reserved
2.0 Status information
- Receive
Status - ON <<
Dependent on the
control function
2.1 Status - ON <
2.2 Status - OFF
2.3 Status - ON >
2.4 Status - ON >>
2.5 Status - Start active BU1 BU2
2.6 Status - Interlocking time active All reversing starters
and positioners
2.7 Status - Change-over pause active Star-delta, Dahlander,
pole-changing
starters
3.0 Status - Runs in open direction
Dependent on the
control function
3.1 Status - Runs in close direction
3.2 Status - FC
3.3 Status - FO
3.4 Status - TC
3.5 Status - TO
3.6 Status - Cold starting (TPF) BU1 BU2 M
3.7 Status - OPO BU2
4.0 Status - Remote mode BU1 BU2
4.1 Status information
- Protection
Status - Emergency start executed IM UM M
4.2 Status - Cooling down period active IM UM M
4.3 Status - Pause time active IM UM
4.4 Status information
- Miscellaneous
Status - Device test active BU1 BU2
4.5 Status - Phase sequence 1-2-3 UM
4.6 Status - Phase sequence 3-2-1 UM
4.7 Status - DM-F enabling circuit DM-F
Table B-9: Data record 92 - Diagnostics
