Siemens SIMOCODE pro

Dimension drawings
SIMOCODE pro
C-4 GWA 4NEB 631 6050-22 DS 03
C.2.2 Current measuring module (through-hole converter)
3UF7102, 10 A to 100 A
Fig. C-4: Current measuring module (through-hole converter) 3UF7102, 10 A to 100 A
55 67
94
65
14
5
T1
T2
T3
