Siemens SIMOCODE pro System Manual

Data formats and data records
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
B-13
5.0 Events - Protection Event - Overload operation
IM UM
5.1 Event - Unbalance IM UM
5.2 Event - Overload IM UM
5.3 Event - Overload + phase failure IM UM
5.4 Event - Internal earth fault IM UM
5.5 Event - External earth fault EM
5.6 Event - Warning ext. earth fault EM
5.7 Event - Thermistor overload Th
6.0 Event - Thermistor short circuit Th
6.1 Event - Thermistor open circuit Th
6.2 Event - TM warning T> TM
6.3 Event - TM Trip T> TM
6.4 Event - TM sensor fault TM
6.5 Event - TM out of range TM
6.6 Reserved
7.0 Events - Level
monitoring
Event - Warning I> IM UM
7.1 Event - Warning I< IM UM
7.2 Event - Warning P> UM
7.3 Event - Warning P< UM
7.4 Event - Warning cos phi< UM
7.5 Event - Warning U< UM
7.6 Event - Warning 0/4-20 mA> AM
7.7 Event - Warning 0/4-20 mA< AM
8.0 Event - Trip I> IM UM
8.1 Event - Trip I< IM UM
8.2 Event - Trip P> UM
8.3 Event - Trip P< UM
8.4 Event - Trip cos phi< UM
8.5 Event - Trip U< UM
8.6 Event - Trip 0/4-20 mA> AM
8.7 Event - Trip 0/4-20 mA< AM
9.0 Event - Stalled rotor IM UM
9.1 Reserved
9.3 Event - No start possible BU1 BU2
9.4 Event - No. of starts > BU1 BU2
9.5 Event - Just one start possible BU1 BU2
9.6 Event - Motor operating hours > BU1 BU2
9.7 Event - Motor stop time > BU1 BU2
10.0 Event - Limit 1 BU2
10.1 Event - Limit 2 BU2
Byte.Bit Designation Information DP
Diagn.
*)
Error No.
***)
Table B-9: Data record 92 - Diagnostics (Cont.)
