Data formats and data records
SIMOCODE pro
B-14 GWA 4NEB 631 6050-22 DS 03
10.2 Event - Limit 3 BU2
10.3 Event - Limit 4 BU2
10.4 Events -
Miscellaneous
Event - Ext. fault 1 BU1 BU2
10.5 Event - Ext. fault 2 BU1 BU2
10.6 Event - Ext. fault 3 BU1 BU2
10.7 Event - Ext. fault 4 BU1 BU2
11.0 Event - Ext. fault 5 BU2
11.1 Event - Ext. fault 6 BU2
11.2 Reserved
11.3 Reserved
11.4 Event - Analog module open circuit AM
11.5 Event - DM-F safety-oriented
tripping
DM-F
11.6 Event - DM-F - Test requirement DM-F
11.7 Reserved
12.0 Events - Time
stamp function
Event - Timestamping function
active+ok
BU2
12.1 Reserved
12.2 Events -
Miscellaneous
Event - DM-FL safety ok DM-FL
12.3 Event - DM-F PROFIsafe active DM-FP
12.4 Events - System
interface
Event - Configured operator panel
missing
BU1 BU2
12.5 Event - Module not supported BU1 BU2
12.6 Event - No module voltage BU2
13.0 Events - Memory
module
Event - Memory module read in BU1 BU2
13.1 Event - Memory module
programmed
BU1 BU2
13.2 Event - Memory module erased BU1 BU2
13.3 Reserved
13.7 Event - Addressing
plug
Event - Addressing plug read in BU1 BU2
14.0 Events -
Parameterization
Event - Start-up parameter block
active
BU1 BU2 M
14.1 Event - Parameter changes not
allowed in the current operating
state
BU1 BU2 M
14.2 Event - Device does not support the
required functions
BU1 BU2 M
14.3 Event - Wrong parameter BU1 BU2 M
14.4 Event - Wrong password BU1 BU2 M
14.5 Event - Password protection active BU1 BU2
Byte.Bit Designation Information DP
Diagn.
*)
Error No.
***)
Table B-9: Data record 92 - Diagnostics (Cont.)
