Siemens SIMOCODE pro System Manual

Data formats and data records
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
B-15
14.6 Event - Factory settings BU1 BU2
14.7 Event - Parameterization active BU1 BU2
15.0 Event - PRM error number (bytes)
**)
BU1 BU2
16.0 Event - DM-FL configuration mode DM-FL
16.1 Event - DM-FL configuration
deviation
DM-FL
16.2 Event - DM-FL waiting for start-up
test
DM-FL
16.3 Event - DM FP PRM error DM-FP
16.4 Reserved
17.0 Warnings -
Protection
Warning - Overload operation IM UM W
17.1 Warning - Unbalance IM UM W
17.2 Warning - Overload IM UM W
17.3 Warning - Overload + phase failure IM UM W
17.4 Warning - Internal earth fault IM UM W
17.5 Warning - External earth fault EM W
17.6 Reserved
17.7 Warning - Thermistor overload Th W
18.0 Warning - Thermistor short circuit Th W
18.1 Warning - Thermistor open circuit Th W
18.2 Warning - TM warning T> TM W
18.3 Reserved
18.4 Warning - TM sensor fault TM W
18.5 Warning - TM out of range TM W
18.6 Reserved
19.0 Warnings -
Level monitoring
Warning - Warning I> IM UM W
19.1 Warning - Warning I< IM UM W
19.2 Warning - Warning P> UM W
19.3 Warning - Warning P< UM W
19.4 Warning - Warning cos phi < UM W
19.5 Warning - Warning U< UM W
19.6 Warning - Warning 0/4-20 mA> AM W
19.7 Warning - Warning 0/4-20 mA< AM W
20.0 Warning - Stalled rotor IM UM W
20.1 Reserved
20.3 Warning - No start possible BU1 BU2 W
20.4 Warning - Number of motor starts> BU1 BU2 W
20.5 Warning - Just one start possible BU1 BU2 W
20.6 Warning - Motor operating hours > BU1 BU2 W
20.7 Warning - Motor stop time > BU1 BU2 W
Byte.Bit Designation Information DP
Diagn.
*)
Error No.
***)
Table B-9: Data record 92 - Diagnostics (Cont.)
