Data formats and data records
SIMOCODE pro
B-16 GWA 4NEB 631 6050-22 DS 03
21.0 Warnings -
Miscellaneous
Warning - Ext. fault 1 BU1 BU2 W
21.1 Warning - Ext. fault 2 BU1 BU2 W
21.2 Warning - Ext. fault 3 BU1 BU2 W
21.3 Warning - Ext. fault 4 BU1 BU2 W
21.4 Warning - Ext. fault 5 BU2 W
21.5 Warning - Ext. fault 6 BU2 W
21.6 Reserved
21.7 Reserved
22.0 Warning - Analog module open
circuit
AM W
22.1 Warning - DM-F safety-oriented
tripping
DM-F W
22.2 Warning - DM-F test requirement DM-F W
22.3 Reserved
22.6 Warning - DM-F feedback circuit DM-F W
22.7 Warning - DM-FL simultaneity DM-FL W
23.0 Trips -
General
Trip - HW fault basic unit BU1 BU2 F9 0
23.1 Trip - Module fault
(e.g. IM, UM, DM module)
BU1 BU2 F9 1
23.2 Trip - Temporary components (e.g.
memory module)
BU1 BU2 F9 2
23.3 Trip - Configuration fault BU1 BU2 F16 3
23.4 Trip - Parameterization BU1 BU2 F16 4
23.5 Trip - Bus BU1 BU2 5
23.6 Trip - PLC/PCS BU1 BU2 6
23.7 Reserved
24.0 Trips -
Receive
Trip - Runtime ON CF = positioner F 8
24.1 Trip - Execution STOP command CF = positioner F 9
24.2 Trip - FB ON CF = positioner F 10
24.3 Trip - FB OFF CF = Positioner F 11
24.4 Trip - Stalled positioner CF = positioner F 12
24.5 Trip - Double 0 CF = positioner F 13
24.6 Trip - Double 1 CF = positioner F 14
24.7 Trip - End position CF = positioner F 15
25.0 Trip - Antivalence CF = positioner F 16
25.1 Trip - Cold starting (TPF) fault BU1 BU2 F 17
25.2 Trip - UVO fault BU2 F 18
25.3 Trip - OPO fault BU2 F 19
25.4 Reserved
26.0 Reserved
Byte.Bit Designation Information DP
Diagn.
*)
Error No.
***)
Table B-9: Data record 92 - Diagnostics (Cont.)
