Data formats and data records
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
B-17
26.1 Trip - Protection Trip - Unbalance IM UM F 25
26.2 Trip - Overload IM UM F 26
26.3 Trip - Overload + phase failure IM UM F 27
26.4 Trip - Int. earth fault IM UM F 28
26.5 Trip - Ext. earth fault EM F 29
26.6 Reserved
26.7 Trip - Thermistor overload Th F 31
27.0 Trip - Thermistor short circuit Th F 32
27.1 Trip - Thermistor open circuit Th F 33
27.2 Reserved
27.3 Trip - TM trip T> TM F 35
27.4 Trip - TM sensor fault TM F 36
27.5 Trip - TM out of range TM F 37
27.6 Reserved
28.0 Trips - Level
monitoring
Trip - Trip I> IM UM F 40
28.1 Trip - Trip I< IM UM F 41
28.2 Trip - Trip P> UM F 42
28.3 Trip - Trip P< UM F 43
28.4 Trip - Trip cos phi< UM F 44
28.5 Trip - Trip U< UM F 45
28.6 Trip - Trip 0/4-20 mA> AM F 46
28.7 Trip - Trip 0/4-20 mA< AM F 47
29.0 Trip - Stalled rotor IM UM F 48
29.1 Reserved
29.4 Trip - Number of starts > BU1 BU2 F 52
29.5 Reserved
30.0 Trips -
Miscellaneous
Trip - External fault 1 BU1 BU2 F 56
30.1 Trip - External fault 2 BU1 BU2 F 57
30.2 Trip - External fault 3 BU1 BU2 F 58
30.3 Trip - External fault 4 BU1 BU2 F 59
30.4 Trip - External fault 5 BU2 F 60
30.5 Trip - External fault 6 BU2 F 61
30.6 Reserved
30.7 Reserved
31.0 Trip - Analog module open circuit AM F 64
31.1 Trip - Test trip BU1 BU2 F 65
31.2 Trip - DM-F safety-oriented tripping DM-F F
31.3 Trip - DM-F wiring DM-FL F
31.4 Trip - DM-FL cross circuit DM-FL F
31.5 Reserved
Byte.Bit Designation Information DP
Diagn.
*)
Error No.
***)
Table B-9: Data record 92 - Diagnostics (Cont.)
