Siemens SIMOCODE pro System Manual

Communication
SIMOCODE pro
12-16 GWA 4NEB 631 6050-22 DS 03
Alarms - process alarm
Process faults, warnings and status information are alarm sources for
process alarms.
As soon as SIMOCODE pro sets a process alarm, the OB 40 process alarm
is started in the SIMATIC S7.
Process alarm - configuration
The process alarm is configured as follows:
Fig. 12-9: Configuration of the process alarm
The first byte of the block for process alarms can be moved by 3 or 6 bytes
depending on the number of blocks for channel-related diagnostics.
Detailed status information can be found in Chapter A.5 "Detailed messages
of the slave diagnostics".
0 0 0 1 0 1 0 0
= 0x14
Length of the process alarm
including header byte (= 20 bytes)
70
70
x
0x00
Slot number
Process alarm
GSD:
OM SIMOCODE pro: 0x04
0x01
7 6 543210
Bit number
Byte 28+n
Byte 29+n
Byte 30+n
Byte 31+n
Byte 32+n
Byte 48+n
Detailed status information
n = 0; 3; 6
7 6 50
Bit number
0x02

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
