Siemens SIMOCODE pro System Manual

Tables
SIMOCODE pro
A-6 GWA 4NEB 631 6050-22 DS 03
38 Reserved
39 Reserved
40 DPV1/RS-232 interface
(acyclic data)
Acyclic Receive - Bit 0.0 BU1 BU2
41 Acyclic Receive - Bit 0.1 BU1 BU2
42 Acyclic Receive - Bit 0.2 BU1 BU2
43 Acyclic Receive - Bit 0.3 BU1 BU2
44 Acyclic Receive - Bit 0.4 BU1 BU2
45 Acyclic Receive - Bit 0.5 BU1 BU2
46 Acyclic Receive - Bit 0.6 BU1 BU2
47 Acyclic Receive - Bit 0.7 BU1 BU2
48 Acyclic Receive - Bit 1.0 BU1 BU2
49 Acyclic Receive - Bit 1.1 BU1 BU2
50 Acyclic Receive - Bit 1.2 BU1 BU2
51 Acyclic Receive - Bit 1.3 BU1 BU2
52 Acyclic Receive - Bit 1.4 BU1 BU2
53 Acyclic Receive - Bit 1.5 BU1 BU2
54 Acyclic Receive - Bit 1.6 BU1 BU2
55 Acyclic Receive - Bit 1.7 BU1 BU2
56 PLC/PCS interface PLC [DPV0]
(cyclic data)
Cyclic Receive - Bit 0.0 BU1 BU2
57 Cyclic Receive - Bit 0.1 BU1 BU2
58 Cyclic Receive - Bit 0.2 BU1 BU2
59 Cyclic Receive - Bit 0.3 BU1 BU2
60 Cyclic Receive - Bit 0.4 BU1 BU2
61 Cyclic Receive - Bit 0.5 BU1 BU2
62 Cyclic Receive - Bit 0.6 BU1 BU2
63 Cyclic Receive - Bit 0.7 BU1 BU2
64 Cyclic Receive - Bit 1.0 BU1 BU2
65 Cyclic Receive - Bit 1.1 BU1 BU2
66 Cyclic Receive - Bit 1.2 BU1 BU2
67 Cyclic Receive - Bit 1.3 BU1 BU2
68 Cyclic Receive - Bit 1.4 BU1 BU2
69 Cyclic Receive - Bit 1.5 BU1 BU2
70 Cyclic Receive - Bit 1.6 BU1 BU2
71 Cyclic Receive - Bit 1.7 BU1 BU2
72 Enabled control command Enabled control command - ON <<
Dependent on the control
function
73 Enabled control command - ON <
74 Enabled control command - OFF
75 Enabled control command - ON >
76 Enabled control command - ON >>
77 Reserved
78 Reserved
79 Reserved
No. Designation Designation Information
Table A-3: Socket assignment table - digital (Cont.)

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
